High-visibility clothing is a good idea, right? If you slap some reflective bits on your clothes and go out for a walk at night, any headlight beams that land on you will be reflected back at the driver, making it easier for them to see you. It works on human drivers, but what about active safety systems – do they “see” a pedestrian’s reflective clothing, and does it help the system detect the wearer? According to recently published testing by the Insurance Institute for Highway Safety, pedestrians wearing reflective clothing at night might actually be less visible to some vehicles’ automatic emergency braking systems than if they were wearing non-reflective light-colored clothing, or even all-black outfits in some cases. That doesn’t seem good.
To see how pedestrian-detecting automatic emergency braking systems respond to various types of clothing, the IIHS used three compact crossovers from the 2023 model year, a Honda CR-V, a Mazda CX-5, and a Subaru Forester. Environmental illumination levels of zero lux (pitch black), 10 lux, or the federally recommended 20 lux of roadway illumination were tested, along with various garments. All tests were performed at 25 mph, with the dummy traveling across a crosswalk. While the Subaru performed extremely well, many of the other results are concerning to say the least, considering reflective clothing is supposed to be safer at night.
If it’s dark out and you’re being approached by a Honda CR-V driven by someone not paying attention, you might be better off wearing black clothing than a highly retroreflective jacket. IIHS researchers found zero speed reduction for the dummy wearing a reflective shell jacket under all lighting conditions. Meanwhile, the black outfit clocked speed reductions of nine percent in 10 lux illumination and 39 percent in 20 lux illumination. Still not great, but better than being hit at a full 25 mph.
The Mazda CX-5 fared better, shedding more speed when the dummy was wearing a fully reflective jacket than when the dummy wasn’t, but its system is not without blind spots. The IIHS also tested clothing with reflective strips, like you might get on workwear or dark-colored jackets and sweatpants designed for runners, and the results across all cars weren’t optimal. As the IIHS put it:
“The placement and motion of reflective strips on the joints and limbs of pants and jackets allows drivers to quickly recognize the pattern of movement as a person,” said study author David Kidd, a senior research scientist at IIHS. “Unfortunately, the moving strips didn’t have the same effect for the pedestrian AEB systems we tested and probably confounded their sensors.”
For the dummy wearing clothing with reflective strips, the Mazda CX-5’s automatic emergency braking system didn’t shed any speed at all regardless of lighting conditions. It’s the same deal with the Honda CR-V, no speed reduction through automatic emergency braking whatsoever. Even the Subaru Forester, which otherwise aced the testing, showed an uncharacteristic dip in performance when it didn’t come to a complete stop for the dummy wearing the clothing with reflective strips in 10 lux lighting conditions. This is particularly weird when you consider the Forester came to a complete stop under all lighting conditions when the dummy was wearing black clothing with no reflective properties.
So what’s going on here? Well, different manufacturers use different algorithms and sensing suites for their advanced driver assistance systems, but they usually consist of both radar units and cameras. The exception here is Subaru. Its Eyesight system is vision-based, relying solely on a pair of stereoscopic cameras. It’s possible that Eyesight is just better at processing images than some other systems because it doesn’t have radar to lean on, but that’s merely a hunch. As of right now, IIHS researchers don’t know why clothing with high-vis strips may be invisible to both the Mazda and the Honda, writing:
It’s not clear why the Honda and Mazda systems struggled with the reflective strips or how many other systems might have trouble identifying pedestrians wearing this type of clothing. However, the lapse is a concern, considering the number of roadway workers and emergency personnel who use similar garments to mitigate risk when they’re working on the road. Further research is needed to determine how crash avoidance systems respond to the specific safety equipment used by such workers.
As of right now, only one thing’s certain, and we’ve repeated it time and time again: Advanced driver assistance systems including automatic emergency braking are not substitutes for attentive drivers. Eyes on the road, people. Driving is serious business, and lives are quite literally on the line.
